CNC Milling Capabilities

Rable Machine boasts a well-equipped CNC machine shop with full, 4-axis vertical machining centers with rotating cutters that perform quick and efficient slot cutting, planing, milling, and drilling operations. During CNC machining, our worktable moves in numerous dimensions around the part.

Our innovative CNC milling and drilling technology offers live tooling capabilities, a large, 40” X 20.1” X 22" work envelope, and automatic pallet changers for added manufacturing efficiency. We work with a wide variety of materials, meeting ultra-tight tolerances as close as ± 0.0002” on all part dimensions.

From one-off prototypes to high-volume, long-run production, our ISO-compliant CNC milling and drilling services meet the diverse needs of multiple industries. Contact Rable Machine to learn more about our CNC milling and drilling capabilities or any of our other precision machining services.

• Our CNC milling centers use a rotating cutter for quick and efficient slot cutting, planing, milling and drilling. The work tables are capable of moving in multiple dimensions around the part being machined enabling us to perform a wide range of operations with this equipment.

• Our four axis vertical machining center has greatly increased both the capacity and the size of parts we can machine for a customer. One mill has a 40" X 20"table and a 40 taper 24 tool chamber.
• Overall, we have 20 CNC vertical machining centers capable of handling a wide variety of sizes and capabilities. And many of our machines are equipped with dual pallet transfer systems that help us increase capacity by loading and unloading on one side of the machine while machining parts on the other side.
• We can mill/drill part sizes from 35" X; 20" Y; 22"Z and hold tolerances as tight as two microns.
• Some typical components we mill include manifold bodies, gear housings, machined castings, machined forgings, valve bodies, spray nozzles, hydraulic equipment parts and actuator components

Vertical CNC Milling Services

Process Description

Milling is a material removal process in which unwanted material are cut away to create a variety of features on a part. Flat, curved, or irregular surfaces are fed against a rotating cutter containing a number of cutting edges. A vertical milling machine orients the cutter vertically.
